| Hardware Configuration: |
| CPU : Allwinner H616 64-bit quad core |
| ARM Cortex A53 CPU |
| RAM: 2GB / 4GB |
| ROM: 16GB/32GB/64GB |
| LAN: 100M |
| WIFI: 2.4G+5G |
| Software Features: |
| OS: Android 10.0 |
| Package Info: | |
| Machine size | 10.7*10.7*1.8cm |
| Package size | 18.3*11.3*7.5cm |
| Carton Size | 57.2*41*27cm |
| PCS/CTN | 40pcs |
| G.W/CTN | 15.5KG |
| N.W/CTN | 15.2KG |
| Specifications | |
| Output Resolution | Up to 4096 x 2160 4K@60Hz |
| CPU | Allwinner H616 Quad-core ARM Cortex-A53 @ up to 1.5 GHz |
| GPU | Mali-G31 |
| RAM/ ROM | DDR3 2G/4G, Emmc16G/32G/64G |
| Operating System | Android 10 |
| Wireless connectivity | |
| Wi-Fi | 802.11b/g/n/ac 2.4GHz/5GHz |
| Bluetooth | 4.0 |
| Decoder | |
| Video decoder | H.265 Main10 profile up to 2160P@60fps |
| H.264 (Base/Main/High profile 2160P@30fps) | |
| VP9(2160P@ 30fps) | |
| VP8(1080P@ 60fps) | |
| MPEG-1/ MPEG-2/ MPEG-4(1080P@60fps) | |
| WMV9/VC-1(SP/MP/ AP up to 1080P@60fps) | |
| Audio decoder | MP3, AAC, WMA, FLAC, OGG |
| Interface | |
| DC 5v Power Interface | x 1 |
| HDMI2.0 | x 1 |
| 10/100Mbps LAN | x 1 |
| SPDIF | x 1 |
| 3.5mm TRRS(AV) | x 1 |
| USB2.0 | x 2 |
| OTG(micro usb) | x 1 |
| TF card slot | x 1 |
| Dimensions | |
| Length | 107mm |
| Width | 107mm |
| Height | 18mm |
| Weight | 103.7g |
| Packing list | |
| 1 x Android TV box 1 x 5V 2A Power adapter 1 x 80 cm male-male HDMI Cable 1 x Infrared Remote control 1 x User Manual | |
| Product Photo | |
 | |
| Package Included |
 |
